Table Top Screw Capping Machine
Table Top Screw Capping Machine
Next Packaging's high-quality Table top screw capping Capping Machine is used by several Companies for sealing various kinds of screw caps. Equipped with heavy quality AC motor, it is an extremely good machine for cap sealing of plastic bottles of fruit juice, beverages, syrups and others.
With easy setup and sturdy structure, this table top screw capping machine have two Motors for working, one is used for screw capping head to seal the cap and the other motor is used for the UP-DOWN movement of the capping head. If client have multiple height of bottle then height adjustment is given to adjust the height of the capping head accordingly, also the machine is made with heavy duty MS body structure.
Bottle height can be 200mm (maximum). Our company also offers the option of customization according to your needs. Suitable for those units having which work for 8-10 hours a day at a competitive price.
Working:
The operator has to manually place the cap onto the bottle. Then, the bottle would be place at the machine's base plate and the capping head will come down and seal the bottle cap.
Benefits:
Sturdy Design |
Optimum Performance |
Ergonomically Designed |
Low Power Consumption |
High Durability |
Low Maintenance Costs |
Technical Specifications :
Model No. | NEXT-STTSC-51 |
Machine Type | Semi Automatic |
MOC | Aluminium |
Cap Size Diameter | 10-50mm (In Different Models) |
Bottle Height | 40-200mm |
Speed | 15-20 Bottle/Min |
Works For | Screw Caps |
